ATEN PE6108AV User Manual

Appendix
93
PE6208AVA / PE6208AVB / PE6208AVG / PE6208AVX
Function PE6208AVA PE6208AVB PE6208AVG PE6208AVX
Electrical
Nominal Input
Voltage
100-120VAC 100-240VAC 100-240VAC 100-240VAC
Maximum Input
Current
20A (Max), 16A
(UL de-rated)
20A (Max), 16A
(UL de-rated)
16A (Max) 16A
Frequency 50-60Hz
Input Connection A/J:NEMA L5-
20P A2/J2: NEMA
5-20P
NEMA 6-20P IEC 60320 C20 Terminal Block
(3P)
Input Power 2400VA (Max),
1920VA (UL de-
rated)
4600VA (Max),
3680VA (UL de-
rated)
3680 VA (Max) 4800VA (Max)
Outlet Type Total: 8 x NEMA
5-20R
Total: 8 x IEC320
C13
Total: 8 x IEC320
C13
Tot a l: 8 x Term i na l
Block (3P)
Nominal Output
Voltage
100-120VAC 100-240VAC 100-240VAC 100-240VAC
Maximum Output
Current (Outlet)
NEMA 5-20R:
20A (Max) 16A
(UL de-rated)
C13: 15A (Max)
12A (UL de-rated)
C13: 10A 16A (Max)
Maximum Output
Current (Bank)
20A (Max) 16A
(UL de-rated)
20A (Max) 16A
(UL de-rated)
16A (Max) 16A (Max)
Maximum Output
Current (Total)
20A (Max) 16A
(UL de-rated)
20A (Max) 16A
(UL de-rated)
16A (Max) 16A (Max)
Metering Per Bank Level Current, Voltage, VA, PF and KWh Monitoring
Outlet Switching Yes
Environment
Sensor Ports
2
Metering
Accuracy
Voltage range: 100VAC-250VAC +/- 1%
Power range: 100W-5000W +/- 2%
Current range: 0.1A-1A +/- 0.1A, 1A-20A +/- 1%
Communication
10/100 Mbps 1 x RJ-45
RS-232 1 x DB-9
Switches
Power Yes
Physical Properties
Dimensions
(L x W x H)
43.24 x 26.72 x 4.40 cm
3
(17.02 x 10.52 x 1.73 in.
3
)
Weight 3.76kg (8.28lb)
