Chapter 2. Hardware Setup
19
Installation
To install the PDU, refer to the installation diagram below (the numbers in the
diagram correspond to the numbered steps), and do the following:
1. For each device you want to connect, use its power cable to connect from
the device's AC socket to any available outlet on the eco PDU.
For PE6208AVX, please refer to Power Cord Installation (PE6208AVX).
2. Plug the Ethernet cable into the eco PDU's LAN port to connect it to the
network.
3. If you are using sensors in your eco PDU installation, connect them to the
sensor ports on the unit’s rear panel.
Note: Sensors are optional. Please see Optional Accessories, page 5, and
the detailed sensor installation diagrams later in this chapter for
further information.
4. If you choose to use a serial device for control, connect its serial port to the
PE6108AV / PE6208AV / PE8208AV's RS-232 port.
5. Connect the eco PDU's power cord to an AC power source.
Note: We strongly advise that you do not plug the eco PDU into a multi
socket extension cord, since it may not receive enough amperage to
operate correctly.
6. Once you have finished these installation steps, you can turn on the eco
PDU and the connected devices.
Note: We strongly recommend using cable ties and cable bars to safely and
securely route the cables attached to the front of the unit.
