AudioCodes Mediant Series Configuration Note

Configuration Note 4. Configure AudioCodes Mediant Gateway
Version 6.8 21 February 2014
4 Configure AudioCodes Mediant Gateway
Using your Web browser, connect to the gateway's administration interface (the default
address is 192.168.0.2).
After providing the required credentials (the default user name is "Admin" and the default
password is "Admin"), the Home page of the Web interface is displayed.
Use the Full navigation menu tree to perform gateway configuration.
4.1 Configure IP Network Interfaces
The procedure below describes how to assign an IP address to the VoIP / Management
LAN interface.
 To configure the IP network interfaces:
1. Open the IP Interfaces Table page (Configuration tab > VoIP menu > Network > IP
Interfaces Table).
2. Modify the existing LAN network interface:
a. Select the OAMP + Media + Control table row, and click Edit.
b. Configure the interface as follows:
Parameter Value
Interface Mode
IPv4 Manual
IP Address
195.189.192.155 (IP address of gateway)
Prefix Length
25 (subnet mask in bits for 255.255.0.0)
Default Gateway
195.189.192.129
Interface Name
Voice (arbitrary descriptive name)
Primary DNS
80.179.55.100
Secondary DNS
80.179.52.100
Underlying Device
vlan 1
3. Click Submit; the configured IP network interfaces are shown below:
Figure 4-1: Configured Network Interfaces in IP Interfaces Table
