Installation and Configuration Manual 5. Connecting Analog Devices to Lync 2010
SBA for Microsoft Lync 109 December 2010
5.1.15 Step 10: Configure Fax Signaling Method
This step defines how to configure the Fax Signaling Method to G.711 Transport for the calls
between the Media Gateway and the analog devices (ATA’s and embedded Media Gateway FXS
ports).
¾ To configure the Fax Signaling Method parameters:
1. Open the 'SIP General Parameters' page (Configuration tab > Protocol Configuration
menu > Protocol Definition submenu > SIP General Parameters).
Figure 5-12: SIP General Parameters Page
2. From the FAX Signaling Method drop-down list, select ‘G.711 Transport’.
3. From Play Ringback Tone to IP drop-down list, select ‘Play’ to provide a ringback tone to
the analog device in case it transferred to another IP user.
5.1.16 Step 11: Configure General Parameters
Configure general parameters as described in the following sections:
Section 4.6, Defining E1/T1/BRI Trunk
Settings
Section 4.7, Defining Voice Coder
Section 4.8, Define Silen
ce Suppression, Comfort Noise and AGC
Section 4.9, Definin
g Early Media
