Barco DP2K-15C - 3 Physical Installation

4. Lamp & Lamp House
Supported xenon bulb lamps (without lamp house)
Lamp
Type
Order in fo DP2K-12C DP2K-15C DP2K-20C
Osram xenon lamp of 4 kW
4kW DHP R9855937
--
X
Osram xenon lamp of 3 kW 3kW DHP R9855938
-
XX
Osram xenon lamp of 2 kW 2kW DHP R9855956 XXX
Osram xenon lamp of 1.2kW 1200W DHP R9855959 XXX
Ushio xenon lamp of 4 kW DXL40BAF R9855939
--
X
Ushio xenon lamp of 3 kW DXL30BAF R9855940
-
XX
Ushio xenon lamp of 2 kW DXL20BAF R9855955 XXX
Ushio xenon lamp of 2 kW DXL20BAF/2 R9855965 XXX
Ushio xenon lamp of 1.2kW DXL12BAF R9855961 XXX
Philips x enon lamp of 4 kW XDC-4000B R9856370
--
X
X = lamp is available for this projector.
- = lamp cannot be used in this projector.
4.2 Removal of the lamp house
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Lam p casing is very hot after operation. To avoid burns, let the projector cool d ow n for at least 15
minutes before proceeding to the lamp unit replacement.
CAUTION: Due to its high internal p ressure, the la
mp may explode in either hot or cold states if improperly
handled.
Necessary tools
• Flat s crew driver or
• Nut driver 8 mm
How to remove the lamp house of the projector
1. Switch off the projector.
2. Remove the lamp cover.
3. Release the three spring lock screws of the lam p hous e as illustrated.
R5905050 DP2K C-SERIES 10/07/2012
23
