Barco DP2K-C Series User Manual

103R5905752 /16 DP2K C
• 3D-stereo mode : frame sequential (embedded stereosync on DP required from the source)
DisplayPort A and DisplayPort B accept the following video-timings:
2D Formats / Single DP Color depth
Port
Display Mode
640 x 480 @ 60 fps 8 bpc, 10 bpc Single 2D
800 x 600 @ 60 fps 8 bpc, 10 bpc Single 2D
1600 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 800 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 720 @ 60 fps 8 bpc, 10 bpc Single 2D
1680 x 1050 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1080 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
2048 x 1080 @ 48, 60 fps 8 bpc, 10 bpc Single 2D
2048 x 1536 @ 60 fps 8 bpc, 10 bpc Single 2D
2048 x 2160 @ 30, 48, 50, 60 fps 8 bpc, 10 bpc Single 2D
3840 x 2160 @ 24 fps 8 bpc, 10 bpc Single 2D
3D Formats / Single DP
Color depth
Port
Display Mode
1920 x 1080 @ 60 fps 8 bpc, 10 bpc Single 3D
2048 x 1080 @ 60 fps 8 bpc, 10 bpc Single 3D
4K Horizontal SPAN 2D - Full
Color depth
Port
Display Mode
2048 x 2160 @ 30, 48, 50, 60 fps 8 bpc, 10 bpc A+B span 2D
4K Horizontal SPAN 2D - Flat
Color depth
Port
Display Mode
1920 x 2160 @ 30, 48, 50, 60 fps 8 bpc, 10 bpc A+B span 2D
4K Horizontal SPAN 3D
Color depth
Port
Display Mode
2048 x 2160 @ 60 fps 8 bpc, 10 bpc A+B span 3D
Audio formats
• 2 channels / LPCM / 16 bits / 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
• 5.1 format / LPCM / 24 bits / 48 kHz
• 7.1 format / LPCM / 20 bits / 48 kHz
Notes:
• DisplayMode = Single : is applicable to both DisplayPort A, and DisplayPort B input, separately.
• DisplayMode = A+B : inputs DisplayPort A and DisplayPort B are combined to 1 larger image; in this case
the 2 DisplayPort links need to be genlocked ( = synchronous and in phase).
• In all cases :
- Color Space - Color Sampling:
◦ YCbCr - 4:4:4
◦ YCbCr - 4:2:2
◦ RGB - 4:4:4
- Scan Type = progressive.
• Both Nvidia and AMD GPU's will not support color depths of 10 bits/color while in 3D-stereo mode.
• Some Graphical Cards may not permit 10 bits/color at all video timings, because of bandwidth restrictions.
• DisplayPort A and DisplayPort B automatically detect:
- Active Pixels, and Active Lines
- Vertical Refresh
- 8 bits/color - 10 bits/color
- Frame locked
• All input resolutions are scaled towards the desired resolution specified in the screen presentation file.
ICMP-X
