2.2.2 EL2014 - Technical data
Technical data EL2014
Connection technology 1-wire
digital outputs 4
Rated load voltage 24V
DC
(-15%/ +20%)
Load type ohmic, inductive, lamp load
Distributed clocks No
Max. output current 0.5A (short-circuit-proof) per channel
Short circuit current < 1A typ.
Breaking energy < 150mJ/channel
Output stage push (high-side switch)
Reverse voltage protection Yes
Switching times T
ON
: 50µs typ., T
OFF
: 100µs typ.
Supply voltage for electronic Via the power contacts
Current consumption via E-bus typ. 60mA
Recommended cycle time ≥ 200µs; with cycle times < 200µs the process data is not
updated in each cycle.
Current consumption of power contacts typ. 15mA + load
Electrical isolation 500V (E-bus/field voltage)
Bit width in process image 4-bit output and 20-bit diagnostics
Supports NoCoeStorage [}68] function
Yes
Configuration via System Manager
Conductor types solid wire, stranded wire and ferrule
Special features diagnostics via process data and LED: overtemperature,
PowerFail, short circuit (per channel)
Weight approx. 70g
Permissible ambient temperature range
during operation
0 °C ... +55 °C
Permissible ambient temperature range
during storage
-25 °C ... +85 °C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}72]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE,
IECEx
