Product overview, digital output terminals
EL20xx, EL212458 Version: 5.2
2.7 EL2124 - Introduction
Fig.40: EL2124
Four-channel digital output terminal 5 V
DC
, CMOS output
The digital output terminal EL2124 connects the binary control signals of the automation device in an
electrically isolated manner to the actuators at the process level and generates load currents with outputs
that are protected against overload and short-circuit. The EtherCAT Terminal contains four channels whose
signal state is indicated by LEDs.
CAUTION
Watchdog settings
Please refer to section "Notes for setting the watchdog [}62]".
