Technical description
6.3 Overview
Note
Composition of the starter kit
This section exclusively deals with the XTS components of the starter kit.
Basic components
• Stand and holder for all mechanical parts
• Industrial PC with all necessary interfaces and sufficient system performance
• TwinCAT NC PTP and XTS function package
• 24 V DC and 48 V DC power supply units
• CU2508 Real-time Ethernet port multiplier
XTS starter kit small AT2000-0500, 500 mm, straight length
Pos. Number Product description Item number
1 1 XTS straight module with connecting cable and EtherCAT
interface
AT2001-0250
2 3 XTS straight module AT2000-0250
3 2 XTS curved module 180° (clothoid) AT2050-0500
4 5 Movers including rollers, magnetic plates and encoder flag AT9011-0050-0550
5 1 Software license TwinCAT TC3 XTS Extension TF5850-0080
6 1 TwinCAT 3 PLC/ NC PTP 10 TC1250-0080
7 1 TwinCAT 3 Scope View Professional* TC1300-0080
8 1 TwinCAT 3 Scope Server* TF3300-0080
9 1 TwinCAT 3 CAM Design Tool* TE1510
10 1 TwinCAT 3 NC Camming* TF5050-0080
11 2 Guide rail, 180° (clothoid) AT9050-0500
12 1 Guide rail straight with lock AT9100-0500
13 1 Guide rail straight without lock AT9000-0500
XTS starter kit medium AT2000-1000, 1000 mm, straight length
Pos. Number Product description Item number
1 1 XTS straight module with connecting cable and EtherCAT
interface
AT2001-0250
2 7 XTS straight module AT2000-0250
3 2 XTS curved module 180° (clothoid) AT2050-0500
4 10 Movers including rollers, magnetic plates and encoder flag AT9011-0050-0550
5 1 Software license TwinCAT TC3 XTS Extension TF5850-0080
6 1 TwinCAT 3 PLC/ NC PTP 10 TC1250-0080
7 1 TwinCAT 3 Scope View Professional* TC1300-0080
8 1 TwinCAT 3 Scope Server* TF3300-0080
9 1 TwinCAT 3 CAM Design Tool* TE1510
10 1 TwinCAT 3 NC Camming* TF5050-0080
11 2 Guide rail, 180° (clothoid) AT9050-0500
12 1 Guide rail straight with lock AT9100-1000
13 1 Guide rail straight without lock AT9000-1000
eXtended Transport System Start-Up24
Version: 1.2
