95
INTRODUCTION NAVIGATION RADIO CD / MP3 CD CHANGER SETUP APPENDIX
Specifications
Voltage supply
Operating voltage: 10.8 - 14.4 V
Current consumption: max. 10 A
Power consumption for
30 minutes after switching off: 550 mA typical
Standby current consumption: 12 mA
Standby current consumption
after 72 hours have elapsed: < 2 mA
Amplifier
Output power: 4 x 25 watts sine in accordance
with DIN 45 324 at 14.4 V
4 x 45 watts max. power
Tuner
Wavebands:
FM: 87.5 - 108 MHz
MW: 531 - 1602 kHz
LW: 153 - 279 kHz
FM frequency response: 35 - 16,000 Hz
CD
Frequency response: 20 - 20,000 Hz
Pre-amp out
4 channels: 3 V
Input sensitivity
CDC input: 2 V / 6 kΩ
Telephone input: max. 4.8 V, eff. 3.8 V
Subject to technical changes!
