Installation instructions
Safety notices
Please observe the following safety
notices during installation and whilst
making the connections.
• Disconnect the negative terminal of the
battery! When doing so, please ob-
serve the safety notices provided by
the vehicle manufacturer.
• When drilling holes, always make sure
that none of the vehicle’s components
can be damaged in the process.
• The cross section of the positive and
negative cables must be at least
1.5 mm
2
.
• Do not connect any of the vehicle’s
plugs directly to the TravelPilot!
• You can obtain the adapter cables re-
quired for your vehicle type from your
Blaupunkt dealer.
• Depending on the vehicle model, the
conditions in your vehicle may differ
from the description provided here. We
do not accept liability for any damages
caused by mistakes made during in-
stallation or when making connections
or for any consequential damages.
If these instructions are not suitable for
your particular installation, please con-
tact your Blaupunkt dealer, your vehi-
cle manufacturer or our telephone hot-
line.
• Battery voltage 10.5-14.4 V
• Negative terminal on the vehicle body
1. Electrical connection
1.1 Electrical connection to the
vehicle-specific plugs
If your car radio connection in your
vehicle has already been fitted at the
factory with 10 A fuse protection (see
operating instructions or your vehicle’s
fuse box), you will additionally need the
vehicle-specific adapter cable (see
Fig. 1).
A vehicle-specific adapter cable
must also be used even in vehicles
that are already fitted with ISO plugs.
2. Loudspeaker connection
2.1 Loudspeaker connection to
standard ISO plug
The loudspeaker connection is made
in chamber B (see Fig. 2).
If the vehicle is prefitted for a pas-
sive installation (with 4-ohm loud-
speakers), you can convert the ISO
plug that is present in the vehicle. If
required, you can extend it using the
ISO cable (Order no. 7 607 647 093).
If the vehicle is prefitted for an ac-
tive installation, you can obtain spe-
cial adapter cables from your dealer.
