BMW HP4 User Manual

Engage the fairing side panel in
mount 6 on the engine spoiler.
Seat the side panel in the rub-
ber buffer at position 4.
Install screws 3 with the wash-
ers.
Install screws 2.
Install screw 1.
Hold slipstream deflector 2 in
position, making sure that it is
the correct part for the side of
the motorcycle on which you
are working.
The letter "R" for right or "L"
for left is stamped on the back
of the slipstream deflector.
Install screws 1.
Installing front flashing
turn indicator
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Remove screws 1 and remove
slipstream deflector 2.
6
111
z On the race track

BMW HP4 Specifications

General

Displacement	999 cc
Torque	112 Nm at 9, 750 rpm
Transmission	6-speed
Seat Height	820 mm
Fuel Tank Capacity	17.5 liters
Dry Weight	169 kg
Suspension	Dynamic Damping Control (DDC)
Engine Type	Water-cooled 4-cylinder 4-stroke in-line engine
Power	193 hp at 13, 000 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Aluminum swing arm
Front Brakes	Twin disc brakes
Rear Brakes	Single disc brake
Frame	Aluminum composite bridge frame
Tires	Front: 120/70 ZR 17, Rear: 200/55 ZR 17
Weight	199 kg (wet)
