From the front, work the anti-
theft alarm into position in the
holder.
Install screw 4.
Connect the plug, making sure
that retainers 3 engage.
with Passenger Bundle
OE
Installing rear seat ( 56).
Removing and installing
front turn indicators
Removing front flashing
turn indicator
The procedure described
here for the right side apply
applies by analogy to the left side
panel.
Remove the side panel
( 137).
Unclip the turn-signal cable at
position 1.
Remove screw 2 and remove
the turn indicator. Work the
cable through the fairing side
panel.
Protect the plug on the motor-
cycle to prevent the ingress of
foreign matter.
6
110
z
