BMW HP4 User Manual

8 Open-ended spanner
Width across flats 10/13
Adjust the chain tension
( 142).
9 Reversible-blade screw-
driver with star-head and
plain tips
Remove the battery
( 162).
10 Reversible screwdriver
blade
Phillips PH1 and Torx T25
Remove the front seat
( 57).
Removing and installing
body panels
Replacing bulbs for front
and rear turn indicators
( 157).
Engine oil
Checking engine oil level
The oil level varies with
the temperature of the
oil. The higher the temperature,
the higher the level of oil in the
sump. Checking the oil level with
the engine cold or after no more
than a short ride will lead to mis-
interpretation of oil level.
In order to ensure that the en-
gine oil level is read correctly,
check the oil level only after at
engine operating temperature.
Make sure the engine is at op-
erating temperature and hold
the motorcycle upright.
Allow the engine to idle for one
minute.
Switch off the ignition.
Check the oil level in oil-level
indicator 1.
Engine oil, specified level
between MIN and MAX marks
9
131
z Maintenance

BMW HP4 Specifications

General

Displacement	999 cc
Torque	112 Nm at 9, 750 rpm
Transmission	6-speed
Seat Height	820 mm
Fuel Tank Capacity	17.5 liters
Dry Weight	169 kg
Suspension	Dynamic Damping Control (DDC)
Engine Type	Water-cooled 4-cylinder 4-stroke in-line engine
Power	193 hp at 13, 000 rpm
Front Suspension	Upside-down telescopic fork
Rear Suspension	Aluminum swing arm
Front Brakes	Twin disc brakes
Rear Brakes	Single disc brake
Frame	Aluminum composite bridge frame
Tires	Front: 120/70 ZR 17, Rear: 200/55 ZR 17
Weight	199 kg (wet)
