_______________________________________________________________________
Using Your Printer 33
3.3 Self-Test
Power On Self-Test
If the Printer's power switch is off, begin the Self-Test by using the Power-On
method. With the Printer OFF, load the media (at least 4 inches wide) to be
used and ribbon, (if equipped and/or desired), optionally install one of the Self-
Test Plugs. Press and hold the FEED button and turn the Printer ON. Release
the Feed switch after the Ribbon/Media LED indicator flashes once. The
Printer will then print the two test labels and operation will continue in the
Character Dump Mode.
Figure 3-3 Self-Test Plugs
NOTE: After performing a Power-Up and Self-Test the Printer will be in
'Character Dump Mode'. Turn the Printer OFF
momentarily, then back ON to restore normal operation.
