_____________________________________________________________________________________________________
48 Printing Labels
4.2 Programming Example
The following ASCII text file will generate the label shown in Figure 4-1.
<STX>L<CR>
H07<CR>
D11<CR>
19110080100002510K OHM 1/4 WATT<CR>
1a6210000000050590PCS<CR>
E
10K OHM 1/4 WATT
Figure 4-1 Sample Label
4.3 Printing Bar Codes
The example shown below prints out a Code 3 of 9 bar code with a wide to
narrow bar ratio of 3:1, and can be used to print any of the bar codes shown in
Appendix B by altering the examples fields. Refer to Figures 4-2 and 4-3 for a
brief explanation of the data fields.
<STX>L<CR>
D11<CR>
1A93040001501000123456789<CR>
121100000000100Barcode A<CR>
E
