CAME RBM84-HW User Manual

O
OUT
+
-
RBM84
REM
REM
RBM 84
TOP-A433N
R501N
AF43S
TOP-A433N
AF43S
AT01
AT02
AT04
TOP-432NA
TOP-434MA
T432
T434
TAM432SA
T438
TWIN 2
TWIN 4
RBM84 - Hardware and connections
16
Page
16
16 - Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015 © CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
On Rem, simply connect a
AF43S radio-frequency card and
connect a TOP-A433N antenna
on the Rem base card.
Connect the receiver R501N (that
includes the plug-in radio frequency card
AF43S ) to the RBM84. The antenna Top-
A433N is also connected to the receiver.
TAM series.
TOP series.
ATOMO series
52 OHM IMPEDENCE
MAX LENGTH: 10 m
52 OHM IMPEDENCE
MAX LENGTH: 10 m
MAX LENGTH: 50 m
TWIN series in
TOP-TAM mode
Connection RBM84/REM <----> Sensor: remote control
