CANCELLI AUTOMATICI
R700
CANCELLI AUTOMATICI
R700
REM
RBM84
RBM84
REM
RBM84 -
Hardware and connections
19
Page
19
19 -
Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015
© CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
TSP00
Transponder card reader
TST01
Transponder
proximity card
Red=S1
Black=GND
Black=GND
Red=S1
Maximum distance: 50m
Maximum distance: 50m
TSP00
Transponder card reader
TST01
Transponder
proximity card
Connection RBM84/REM <----> Transponder sensor for proximity devices
