CAME RBM84-HW User Manual

RBM84
REM
RBM84
REM
Wave (WA01)
Wave (WA01)
RBM84 - Hardware and connections
23
Page
23
23 -
Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015
© CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
230 VAC power supply
Relay contact
230 VAC power supply
Relay contact
Connection RBM84/REM <----> WAVE connection
Cable NOT INCLUDED
recommended type:
unshielded
multipair cable
(CAT 5 - U/UTP - AWG24)
see Annex A
Cable NOT INCLUDED
recommended type:
(CAT 5 - U/UTP - AWG24)
see Annex A
