CAME RBM84-HW User Manual

Came
cancelli automatici
s.p.a.
via Martiri della Libertà, 15
31030 Dosson di Casier
Treviso - Italy
tel. (+39) 0422 4940
fax (+39) 0422 4941
www.came.it
info@came.it
Came Cancelli Automatici
è una società certificata
ISO 9001 per il sistema
di gestione della qualità
aziendale e ISO 14001
per il sistema di gestione
ambiantale.
Came progetta e produce
interamente in Italia.
*
*
*
*
*
PSINS
PSSRV
REM
REM
WA01
PST001
(Twister)
PSHPS07
(Guardian)
RBM84 - Hardware and connections
6
Page
6
- Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015 © CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
*
Recommended cable: unshielded braided multi-strand (CAT 5 - U/UTP - AWG 24)
Types of compatible commands
Transmitters
ATOMO/TOP/TAM
TWIN
Transponder card
sensors
TSP00/TST01
Transponder
keychain
PCT/TAG
Magnetic card
sensor
LT001/TST02
Transponder sensor
WA01
Keypad
selectors
S5000/S6000
S7000
PC with operating system
Windows Xp/7/8
RBM84
Control unit
Software
PC30
Interface
Cables x 1.5 mm² for 230 V AC
Cables x 1.5 mm² for 230 V AC
Barriers or other operators
RS232 cable
Max 5 m
Other units
Maximum distance
between RBM84 and
last REM/Turnstile unit
1000 m
Max 1000 m
Schematic diagram

CAME RBM84-HW Specifications
