RBM84
REM
CANCELLI AUTOMATICI
R700
CANCELLI AUTOMATICI
R700
REM
RBM84
RBM84 -
Hardware and connections
20
Page
20
20 - Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015 © CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
Black=GND
Red=S1
Black=GND
Red=S1
Maximum distance: 50m
Maximum distance: 50m
LT001
Swipe reader
for magnetic cards
TST02
Magnetic card
LT001
Swipe reader
for magnetic cards
TST02
Magnetic card
Connection RBM84/REM <----> Sensor for magnetic swipe cards
