RBM84 - Hardware and connections
24
Page
24
24 - Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015 © CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
Provide a suitable omnipolar circuir breaker, with 3 mm maximum distance between contacts to disconnect the
power supply;
230 VAC
"Partial" tra c lights associated to di erent levels or sectors, up to 8 at most, where 4 are controlled
by REM, which in turn is controlled by the software supplied.
① = Black
② = Brown
③ = Blue
Connection RBM84 <----> Tra c lights
