CAME RBM84-HW User Manual

+ -
A B
GND
S2
S1 2
+ -
A B
GND
S2
S1 2
Rbm84
Rem
RBM84 - Hardware and connections
22
Page
22
22 - Manual code:
FA00189M04
FA00189M04 ver.
1
10/2015 © CAME s.p.a. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.a.
PST001 (Twister) Turnstile
*
Connection RBM84/REM <----> Turnstile connection
*
Only with RBM84 software version 3 or later.
PSHPS07 Turnstile (Guardian)
*
PST001 (Twister) Turnstile
*
PSHPS07 Turnstile (Guardian)
*
Cable NOT INCLUDED
recommended type:
unshielded
multipair cable
(CAT 5 - U/UTP - AWG24)
see Annex A
Cable NOT INCLUDED
recommended type:
unshielded
multipair cable
(CAT 5 - U/UTP - AWG24)
see Annex A
