3. If Lever C9427 and Lever for Mask C4137 are out of place,adjustments should be made by bending C9427
upwards.
See Repair Manual pp.2&8.
4. If Lever C9427 and Arm C9428 are out of place the upward and downward play of both should be
adjusted with a washer.
See Repair Manual pp.2&3.
5. If the movement of C9427 is impeded by Lever C9427 and Film Counter Advancing Lever C9431 pressing
against it, C9431 should be bent and adjusted so that it will not touch.
See Repair Manual p. 2.
When the Red Mark does not appear normally, that is, when the Red Mark appears even though the Shutter has
been set for automatic photography, or when the Red Mark does not appear at all after the lens cap has been
put on and the Shutter Button pressed, it may be assumed that something is wrong with the Red Mark itself.
In this case, the following adjustments should be made:
1. If the movement of Moving Guide C4153 is bad, replace Washer W 2132 x 2, which is under Retaining Washer
YS 1131x2 holding C4153, with one of less thickness.
See Repoir Monual p.8.
2. Adjust the length of EE-Signal C4359 after loosening Screw Sl-140157 x 2 securing C4359.
See Repair Monual p.2.
* * *
5
