3. If the gap between Lever C4044 and Winding Device C9266-11 has become too wide because Lever C4044 has become
worn out, adjustments should be made by turning the Hexagonal Eccentric Nut for Base Plate C9262-09 with Spann-
er 2 for C4041. If this is insufficient, C4044 should be replaced.
See Repair Manual p. 5
When the Shutter Button cannot be pressed down, it should be adjusted in the following manner:
Check to see whether Spring C4049 attached to Lever C4051-03 is out of place and if so, reattach.
See Repair Manual p. 5
When the Shutter Button does not return to its original position after it has been pressed down, the following adjustments
should be made:
Check to see whether Cone C4090 is caught between Lever C9267 and Lever C4051-03. If so, loosen Screw SI 777
and make adjustments by turning C4090 to the right.
See Repair Manual pp. 2 & 5.
When the film cannot be rewound or when the film catches, the following adjustments should be made:
Open the Back Cover and set the Rewind Clutch Lever to R. Then check to see whether it will turn both to the left
and right by rotating the sprocket manually. If it does not turn, see whether Clutch Lever C4023 is bent, or whe-
ther Clutch Shaft C4056 is held down properly by C4023. Then adjust by bending C4023, or replace C4023.
See Repair Manual p. 5.
* * *
9
