Canon VB-M40 User Manual

8-4
According to the setting item, you can specify parameters using modifier “% characters.”
Note
• A runtime error will occur if the specified name does not match.
• If this modifier is not defined, “%” will be deleted.
Modifiers
Modifiers Meaning Description of character string entered
%n Reason for capture (number) 0 (test) | 1 (External device input 1) | 2 (External device input 2)|
33 (Timer event) | 145 (Volume detection) |
161 (Intelligent Function Detection Setting 1) | 162 (Intelligent Function Detection Setting 2) |
163 (Intelligent Function Detection Setting 3) | 164 (Intelligent Function Detection Setting 4) |
165 (Intelligent Function Detection Setting 5) | 166 (Intelligent Function Detection Setting 6) |
167 (Intelligent Function Detection Setting 7) | 168 (Intelligent Function Detection Setting 8) |
169 (Intelligent Function Detection Setting 9) | 170 (Intelligent Function Detection Setting 10) |
171 (Intelligent Function Detection Setting 11) | 172 (Intelligent Function Detection Setting 12) |
173 (Intelligent Function Detection Setting 13) | 174 (Intelligent Function Detection Setting 14) |
175 (Intelligent Function Detection Setting 15)
%N Reason for capture
(character string)
<External input device name (alphanumeric characters)> | <Intelligent Function Detection Setting (1
- 15)> | NULL (external input device name (alphanumeric characters) not yet set/volume
detection/timer event or test)
%X Width of image Number of pixels in horizontal direction
%Y Height of image Number of pixels in vertical direction
%C Camera number 1
%D Camera name Setting for [Camera Name (alphanumeric characters)]
%P Pan position 0 -179.99 - 180.00
%T Tilt position 0 -179.99 - 180.00
%Z Zoom position 0 0.01 - 300.00
%V Camera server VB-M700F / VB-M600D / VB-M600VE / VB-M40
%y Year of capture time 2001 – 2031
%m Month of capture time 01 – 12
%d Day of capture time 01 – 31
%w Day of week of capture time 0 – 6 (Sunday to Saturday)
%H Hours of capture time 00 – 23
%M Minutes of capture time 00 – 59
%S Seconds of capture time 00 – 59
%s Milliseconds of capture time 000 – 999
%z Time zone of capture time -1200 – +1300
%a Weekday name of capture
time
Sun | Mon | Tue | Wed | Thu | Fri | Sat
%b Month name of capture time Jan | Feb | Mar | Apr | May | Jun | Jul | Aug | Sep | Oct | Nov | Dec
%h Host Name

Canon VB-M40 Specifications

General

Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264
Supported graphics resolutions	160 x 120, 320 x 240, 1280 x 960, 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Manual
Tilt angle range	-90 - 10 °
Minimum illumination	0.01 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	4 x
Optical zoom	20 x
Focal length range	4.7 - 94 mm
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Form factor	Covert
Product color	Black
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Headphone outputs	1
Cabling technology	10/100Base-T(X)
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Storage temperature (T-T)	5 - 85 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1150 g
