Canon VB-M40 User Manual

1-2
This camera integrates both camera and server functions into a compact network camera.
Common Features
*1 The actual frame rate may drop depending on the performance of the PC running the Viewer, the number of clients
connected at the same time, network load, and other factors.
VB-M40 Features
VB-M700F/VB-M600D/VB-M600VE Features
Features
Megapixel Support
Equipped with a 1.3 megapixel CMOS sensor, the camera supports high-quality video
monitoring.
H.264 Support
In addition to JPEG, the camera supports video compression in H.264 format, which
provides high image quality and high compression rates. 1280x960 resolution video can
be transmitted to up to 10 clients simultaneously (up to 30 clients for JPEG) in high quality
and at a high frame rate of 30 frames per second.*
1
Low Illumination Image Capture
The camera can capture color images even with low subject illumination.
Minimum subject illumination of 0.25 lux (1/30 sec., with smart shade control
OFF)
Minimum subject illumination of 0.4 lux (1/30 sec., with smart shade control OFF)
Intelligent Functions
The camera boasts a variety of intelligent functions that offer the wide array of detection options.
Moving object detection, abandoned object detection, removed object detection,
camera tempering detection, volume detection.
Privacy Masking
You can hide parts of an image with masks to ensure privacy and security.
The mask area tracks camera pan, tilt, and zoom operations and moves
accordingly.
SD/SDHC Memory Card Support
You can record uploaded images and logs to memory cards when the network is down.
Small-Scale Video Monitoring via RM-Lite
Software (Supplied)
By using the supplied network video recording software, RM-Lite, you can record and
display live images from up to four cameras.
20x Optical Zoom Lens
The camera is equipped with a 20x optical (4x digital) zoom lens with a maximum 55.4°
angle of view and auto focus support.
Pan/Tilt Functions
You can operate camera angle controls remotely.
3x Optical Zoom Lens The camera is equipped with a 3x motorized optical zoom lens with a maximum 101.2°
horizontal angle of view.
Camera Angle Setting Tool You can make adjustments to the camera angle while viewing video on a PC for hassle-free
angle adjustment during installation.
Zoom and focus settings are possible.
Pan, tilt, rotation, zoom, and focus settings are possible.
Shock Resistant Structure (VB-M600VE
only)
The camera is built with a shock absorbing mechanism and an exterior casing made of 3.5
mm-thick (0.14 inch-thick) polycarbonate resin and aluminum alloy. The camera's dome
case also uses special screws that cannot be easily removed.
* The features described above do not guarantee that the product will be undamaged if
subjected to an impact, nor that the product is tamper-proof or tamper-resistant.
Dustproof and Waterproof Mechanisms
(VB-M600VE only)
The camera complies with the demanding IP66 dustproof/waterproof specifications and
can be installed under eaves without any housing. The optional genuine heater lets you use
the camera in low-temperature environments as cold as -30°C (-22°F).

Canon VB-M40 Specifications

General

Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264
Supported graphics resolutions	160 x 120, 320 x 240, 1280 x 960, 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Manual
Tilt angle range	-90 - 10 °
Minimum illumination	0.01 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	4 x
Optical zoom	20 x
Focal length range	4.7 - 94 mm
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Form factor	Covert
Product color	Black
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Headphone outputs	1
Cabling technology	10/100Base-T(X)
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Storage temperature (T-T)	5 - 85 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1150 g
