Canon VB-M40 User Manual

5-32
1 [LAN]
LAN interface, maximum packet size settings (P. 5-5)
2 [IPv4]
IP address, IPv4 settings, etc. (P. 5-5)
3 [IPv6]
Settings regarding IPv6 (P. 5-6)
4 [Installation Conditions]
Settings regarding camera installation conditions
(P. 5-11)
5 [H.264]
Settings regarding H.264 image size and frame rate
(P. 5-13)
6 [HTTP Server]
Authentication method, HTTP, and HTTPS port settings
(P. 5-19)
[Reboot Item] Setting Items Requiring Rebooting
The following settings that require rebooting before
changes take effect can be found on a single page.
• LAN, IPv4, IPv6, H.264, Installation Conditions
(VB-M40 only) HTTP Server
Important
These settings relate to network connectivity. If any setting is
changed to a value that may disable camera connection from
the active web browser, a dialog box appears and alerts the
user.
Click [OK] to apply the new setting.
Depending on the new setting, it may not be possible to
connect to the camera again after rebooting. If this happens, a
candidate URI for reconnecting the camera will appear if
available.
Try the URI displayed to reconnect the camera.
If you cannot connect to the camera through the displayed URI,
contact your System Administrator.
* Settings related to network connectivity in the [Reboot Item] menu
are [LAN Interface], [Maximum Packet Size], [IPv4 Address
Setting Method], [IPv4 Address], [Subnet Mask], [IPv4 Default
Gateway Address], [IPv6], [Auto], [IPv6 Address (Manual)],
[Prefix Length], [IPv6 Default Gateway Address], [HTTP Port] and
[HTTPS Port].

Canon VB-M40 Specifications

General

Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264
Supported graphics resolutions	160 x 120, 320 x 240, 1280 x 960, 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Manual
Tilt angle range	-90 - 10 °
Minimum illumination	0.01 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	4 x
Optical zoom	20 x
Focal length range	4.7 - 94 mm
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Form factor	Covert
Product color	Black
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Headphone outputs	1
Cabling technology	10/100Base-T(X)
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Storage temperature (T-T)	5 - 85 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1150 g
