Carrier Aquasnap 30RQ User Manual

5.2 - Physical data 30RB 410R-950R
30RB 410R 450R 480R 550R 610R 670R 720R 770R 800R 870R 950R
Sound levels
Standard unit
Sound power
(1)
dB(A)
93,5 94,0 94,0 94,5 97,5 97,5 98,0 98,0 98,5 98,5 99,0
Sound pressure at 10 m
(2)
dB(A)
61,5 61,5 61,5 62,0 65,0 65,0 66,0 65,0 66,0 66,0 66,5
Unit + option 15LS
(3)
Sound power
(1)
dB(A)
88,0 88,5 88,5 89,0 92,5 92,5 93,0 93,0 93,5 93,5 94,5
Sound pressure at 10 m
(2)
dB(A)
56,0 56,0 56,5 57,0 60,5 60,0 60,5 60,0 61,0 60,5 61,5
Dimensions - standard unit
Standard unit
Length mm
3604 4798 4798 4798 5992 5992 5992 7186 7186 7186 7186
Width mm
2253 2253 2253 2253 2253 2253 2253 2253 2253 2253 2253
Height mm
2324 2324 2324 2324 2324 2324 2324 2324 2324 2324 2324
Unit + option 307
(3)
Length mm
4798 5992 5992 5992 7186 7186 7186 8380 8380 8380 8380
Operating weight
(4)
Standard unit kg
2269 2697 2722 2927 3265 3511 3511 4042 4042 4291 4291
Unit + option 15LS
(3)
kg
2414 2860 2885 3108 3398 3664 3664 4216 4216 4485 4485
Unit + option 15LS + option 116W
(3)
kg
2609 3094 3119 3379 3708 3974 3974 4605 4605 4874 4874
Unit + option 15LS + option 116W + option 307
(3)
kg
3594 4086 4111 4371 4715 4981 4981 5626 5626 5895 5895
Compressors Hermetic Scroll 48,3 r/s
Circuit A
3 3 3 4 2 3 3 3 3 4 4
Circuit B
3 4 4 4 3 3 3 4 4 4 4
Number of power stages
6 7 7 8 5 6 6 7 7 8 8
Unit PED category
III IV IV IV III III III IV IV IV IV
Refrigerant
(4)
R32 / A2L /GWP= 675 as per AR4
Circuit A
kg
18,5 18,8 19,1 24,4 23,0 24,5 24,5 27,3 27,3 30,4 30,4
tCO
2
e
12,5 12,7 12,9 16,5 15,5 16,5 16,5 18,4 18,4 20,5 20,5
Circuit B
kg
19,3 24,5 24,9 25,4 24,5 24,5 24,5 30,4 30,4 30,4 30,4
tCO
2
e
13,0 16,5 16,8 17,1 16,5 16,5 16,5 20,5 20,5 20,5 20,5
Oil
Circuit A l
19,8 19,8 19,8 26,4 13,2 19,8 19,8 19,8 19,8 26,4 26,4
Circuit B l
19,8 26,4 26,4 26,4 19,8 19,8 19,8 26,4 26,4 26,4 26,4
Capacity control
SmartVu
TM
Minimum capacity %
17 14 14 13 20 17 17 14 14 13 13
Condenser All-aluminium micro-channel coils (MCHE)
Fans Axial Flying Bird 6 with rotating shroud
Standard unit
Quantity
6 7 7 8 9 10 10 11 11 12 12
Maximum total air ow l/s
28920 33740 33740 38560 43380 48200 48200 53020 53020 57840 57840
Maximum rotation speed r/s
16 16 16 16 16 16 16 16 16 16 16
Evaporator Direct expansion brazed-plate heat exchanger
Water volume l 44 44 47 53 73 73 73 84 84 84 84
Max. water-side operating pressure without hydraulic module kPa 1000 1000 1000 1000 1000
1000 1000 1000 1000 1000 1000
Hydraulic module (option)
Pump, Victaulic screen lter, relief valve,
water and air vent valve, pressure sensors
Pump
Centrifugal pump, monocell, 48,3 r/s, low- or high pressure
(as required), single or dual (as required)
Expansion tank volume (Option) l 80 80 80 80 80 80 80 80 80 80 80
Bu󰀨er tank volume (option) l 550 550 550 550 550 550 550 550 550 550 550
Max. water-side operating pressure with hydraulic module kPa 400 400 400 400 400 400 400 400 400 400 400
Water connections with or without hydraulic module Victaulic
®
type
Connections inches 4 4 4 4 5 5 5 5 5 5 5
External diameter mm 114,3 114,3 114,3 114,3 139,7 139,7 139,7 139,7 139,7 139,7 139,7
Casing paint colour Colour code RAL 7035
(1) In dB ref=10
-12
W, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). Measured in accordance
with ISO 9614-1 and certied by Eurovent.
(2) In dB ref 20 µPa, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). For information, calculated
from the sound power Lw(A).
(3) Options: 15LS = Very low noise level, 116W = Variable-speed high pressure dual-pump hydraulic module, 307 = Water bu󰀨er tank module,
(4) Values are guidelines only. Refer to the unit name plate.
5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
13
