5.13 - Electrical data notes for the compressors
Compressor I Nom
(1)
I Max (Un)
(2)
I Max
(Un - 10%)
(3)
LRA A
(4)
I start
option
25/25E A
(5)
LRYA A
(6)
LRDA A
(7)
Cos
Phi nom.
(8)
Cos
Phi Max.
(9)
00PSG003209700A 29,7 39,1 A 43 A 215 172 NA NA 0,84 0,85
00PSG003215200A 35,9 47,4 A 51 A 260 208 NA NA 0,84 0,85
00PSG003237600A 56,9 76 A 82 A 413 330 NA NA 0,83 0,84
00PSG003237000A 61,1 82,5 A 88 A 413 330 NA NA 0,84 0,84
(1) Nominal current draw (A) under standard Eurovent conditions (see denition of conditions under nominal unit current draw)
(2) Maximum operating current
(3) Maximum compressor operating current, limited by the unit (current given for maximum capacity at 360 V)
(4) Locked rotor current at nominal voltage, corresponding to the direct start-up current
(5) Locked rotor current with electronic starter at nominal voltage
(6) Locked rotor current in star connection (connection during compressor start-up)
(7) Locked rotor current with delta connection
(8) Values recorded under standard Eurovent conditions: Evaporator water outlet/inlet = 12 °C/7 °C. Condenser water outlet/inlet = 30 °C/35 °C.
(9) Value recorded at maximum capacity and nominal voltage
5.14 - Distribution of compressors per circuit
30RB-30RBP
Compressor Circuit 170R 190R 210R 230R 270R 310R 340R 380R 410R
00PSG003209700A
A 1 2 3
B 2 2 2 3
00PSG003215200A
A 1 1 2 2 2 3
B 2 2 3 3 3
Compressor Circuit 450R 480R 550R 610R 670R 720R 770R 800R 870R 950R
00PSG003209700A
A 3
B
00PSG003215200A
A 3 4
B 4 4 4
00PSG003237600A
A 3 3 4
B 3 4 4 4
00PSG003237000A
A 2 3 3 4
B 3 3 4
30RQ-30RQP
Compressor Circuit 165R 180R 210R 230R 270R 310R 330R 370R 400R
00PSG003209700A
A/C 1 1 2 2 2 2
B/D 2 2
00PSG003215200A
A/C 2 2 2
B/D 2 2 2 3 3 4 4
Compressor Circuit 430R 470R 520R 620R 660R 740R 800R 860R 940R 1040R
00PSG003209700A
A/C 3 2 / 2 2 / 2 3 / 3
B/D
00PSG003215200A
A/C 3 4 2 / 2 2 / 2 3 / 3 4 / 4
B/D 4 4 4 3 / 3 3 / 3 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4
5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
30
