Carrier Aquasnap 30RQ User Manual

5.6 - Physical data 30RQP 620R-1040R
30RQP 620R 660R 740R 800R 860R 940R 1040R
Sound levels
Standard unit
Sound power
(1)
dB(A) 96,0 96,5 97,0 97,0 97,5 97,5 98,0
Sound pressure at 10 m
(2)
dB(A) 63,5 64,0 64,5 64,5 65,0 65,0 65,5
Unit + option 15LS
(3)
Sound power
(1)
dB(A) 91,0 91,0 92,0 92,0 92,5 93,0 93,0
Sound pressure at 10 m
(2)
dB(A) 58,5 58,5 59,5 59,5 60,0 60,5 60,5
Dimensions - standard unit
Standard unit
Length mm 7708 7708 7708 7708 10096 10096 10096
Width mm 2253 2253 2253 2253 2253 2253 2253
Height mm 2324 2324 2324 2324 2324 2324 2324
Unit + option 307
(3)
Length mm - - - - - - -
Operating weight
(4)
Standard unit kg 4787 4905 5344 5356 6308 6360 6859
Unit + option 15LS
(3)
kg 5041 5158 5634 5646 6634 6686 7222
Unit + option 15LS + option 116W
(3)
kg 5430 5548 6102 6114 7103 7229 7764
Unit + option 15LS + option 116W + option 307
(3)
kg - - - - - - -
Compressors Hermetic Scroll 48,3 r/s
Circuit A/C 2/2 2/2 2/2 2/2 3/3 3/3 4/4
Circuit B/D 3/3 3/3 4/4 4/4 4/4 4/4 4/4
Number of power stages 10 10 12 12 14 14 16
Unit PED category III IV IV IV IV IV IV
Refrigerant
(4)
R32 / A2L /GWP= 675 as per AR4
Circuit A/C
kg 16,0 / 16,0 18,0 / 18,0 18,0 / 18,0 18,0 / 18,0 29,0 / 29,0 29,0 / 29,0 35,0 / 35,0
tCO
2
e 10,8 / 10,8 12,2 / 12,2 12,2 / 12,2 12,2 / 12,2 19,6 / 19,6 19,6 / 19,6 23,6 / 23,6
Circuit B/D
kg 28,5 / 28,5 28,5 / 28,5 34,0 / 34,0 34,0 / 34,0 34,5 / 34,5 35,0 / 35,0 35,0 / 35,0
tCO
2
e 19,2 / 19,2 19,2 / 19,2 23,0 / 23,0 23,0 / 23,0 23,3 / 23,3 23,6 / 23,6 23,6 / 23,6
Oil
Circuit A/C l 13,2 / 13,2 13,2 / 13,2 13,2 / 13,2 13,2 / 13,2 22,8 / 22,8 22,8 / 22,8 30,4 / 30,4
Circuit B/D l 22,8 / 22,8 22,8 / 22,8 30,4 / 30,4 30,4 / 30,4 30,4 / 30,4 30,4 / 30,4 30,4 / 30,4
Capacity control SmartVu
TM
Minimum capacity % 10 10 8 8 7 7 6
Condenser Grooved copper tubes and aluminium ns
Fans Axial Flying Bird 6 with rotating shroud
Standard unit
Quantity 10 10 12 12 14 14 16
Maximum total air ow l/s 48200 48200 57840 57840 67480 67480 77120
Maximum rotation speed r/s 16 16 16 16 16 16 16
Evaporator Direct expansion brazed-plate heat exchanger
Water volume l 77,4 97,2 97,2 97,2 97,2 104,4 117
Max. water-side operating pressure without hydraulic
module
kPa 1000 1000 1000 1000 1000 1000 1000
Hydraulic module (option)
Pump, Victaulic screen lter, relief valve,
water and air vent valve, pressure sensors
Pump
Centrifugal pump, monocell, 48,3 r/s, low- or high pressure (as required),
single or dual (as required)
Expansion tank volume (Option) l - - - - - - -
Bu󰀨er tank volume (option) l - - - - - - -
Max. water-side operating pressure with hydraulic module kPa 400 400 400 400 400 400 400
Water connections with or without hydraulic module Victaulic
®
type
Module 1/Module 2 connections
(a)
inches 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4
Module 1/Module 2 external diameter
(a)
mm
114,3 /
114,3
114,3 /
114,3
114,3 /
114,3
114,3 /
114,3
114,3 /
114,3
114,3 /
114,3
114,3 /
114,3
Casing paint colour Colour code RAL 7035
(1) In dB ref=10
-12
W, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). Measured in accordance
with ISO 9614-1 and certied by Eurovent. Cooling mode operation
(2) In dB ref 20 µPa, (A) weighting. Declared dual-number noise emission value in accordance with ISO 4871 with an uncertainty of +/-3 dB(A). For information, calculated
from the sound power Lw(A).
(3) Options: 15LS = Very low noise level, 116W = Variable-speed high pressure dual-pump hydraulic module, 307 = Water bu󰀨er tank module,
(4) Values are guidelines only. Refer to the unit name plate.
(a) Modules 1 and 2 only relate to sizes 620R to 1040R.
5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
18
