5.9 - Electrical data 30RQ 165R-520R
30RQ 165R 180R 210R 230R 270R 310R 330R 370R 400R 430R 470R 520R
Power circuit supply
Nominal voltage V-ph-Hz 400 - 3 - 50
Voltage range V 360 - 440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)or(2)
Circuit A&B kW 74,6 84,2 99,4 109,0 118,6 138,7 148,3 168,3 177,9 193,2 207,6 237,2
Power factor at maximum power
(1)or(2)
Displacement Power Factor (Cos Phi), standard unit 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83
Maximum operating current draw (Un)
(1)or(2)
Standard unit A 129 145,6 172 188,6 205,2 239,9 256,5 291,2 307,8 334,2 359,1 410,4
Maximum current (Un-10%)
(1)or(2)
Standard unit A 140,7 156,7 187,6 203,6 219,6 258,5 274,5 313,4 329,4 360,3 384,3 439,2
Maximum start-up current (Un)
(2)+(3)
Standard unit A 305 362 348 401 418 453 469 504 520 547 572 623
Unit + option 25/25E A 262 310 305 349 366 401 417 452 468 495 520 571
(1) Values at the unit's permanent maximum operating condition (as shown on the unit's nameplate).
(2) Values at the unit's maximum operating condition (as shown on the unit's nameplate).
(3) Maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the largest compressor.
5.10 - Electrical data 30RQP 165R-1040R
30RQP 165R 180R 210R 230R 270R 310R 330R 370R 400R 430R 470R 520R
Power circuit supply
Nominal voltage V-ph-Hz 400 - 3 - 50
Voltage range V 360 - 440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)or(2)
Circuit A&B (Module 1/Module 2)
(a)
kW 74,8 84,4 99,8 109,3 118,9 139,2 148,7 169 178,6 193,7 208,1 237,8
Power factor at maximum power
(1)or(2)
Displacement Power Factor (Cos Phi), standard unit 0,85 0,85 0,85 0,85 0,85 0,85 0,85 0,85 0,85 0,85 0,85 0,85
Maximum operating current draw (Un)
(1)or(2)
Standard unit (Module 1/Module 2)
(a)
A 126,3 142,9 168,4 185 201,6 235,4 252 285,8 302,4 327,9 352,8 403,2
Maximum current (Un-10%)
(1)or(2)
Standard unit (Module 1/Module 2)
(a)
A 138 154 184 200 216 254 270 308 324 354 378 432
Maximum start-up current (Un)
(2)+(3)
Standard unit (Module 1/Module 2)
(a)
A 302 359 344 398 414 448 465 498 515 541 565 616
Unit + option 25/25E (Module 1/Module 2)
(a)
A 259 307 301 346 362 396 413 446 463 489 513 564
30RQP 620R 660R 740R 800R 860R 940R 1040R
Power circuit supply
Nominal voltage V-ph-Hz 400 - 3 - 50
Voltage range V 360 - 440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)or(2)
Circuit A&B (Module 1/Module 2)
(a)
kW
139,2 /
139,2
148,7 /
148,7
169,0 /
169,0
178,6 /
178,6
193,7 /
193,7
208,1 /
208,1
237,8 /
237,8
Power factor at maximum power
(1)or(2)
Displacement Power Factor (Cos Phi), standard unit 0,85 0,85 0,85 0,85 0,85 0,85 0,85
Maximum operating current draw (Un)
(1)or(2)
Standard unit (Module 1/Module 2)
(a)
A
235,4 /
235,4
252 / 252
285,8 /
285,8
302,4 /
302,4
327,9 /
327,9
352,8 /
352,8
403,2 /
403,2
Maximum current (Un-10%)
(1)or(2)
Standard unit (Module 1/Module 2)
(a)
A 254 / 254 270 / 270 308 / 308 324 / 324 354 / 354 378 / 378 432 / 432
Maximum start-up current (Un)
(2)+(3)
Standard unit (Module 1/Module 2)
(a)
A 448 / 448 465 / 465 498 / 498 515 / 515 541 / 541 565 / 565 616 / 616
Unit + option 25/25E (Module 1/Module 2)
(a)
A 396 / 396 413 / 413 446 / 446 463 / 463 489 / 489 513 / 513 564 / 564
(1) Values at the unit's permanent maximum operating condition (as shown on the unit's nameplate).
(2) Values at the unit's maximum operating condition (as shown on the unit's nameplate).
(3) Maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the largest compressor.
(a) Modules 1 and 2 only relate to sizes 620R to 1040R.
5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
21
