5.7 - Electrical data 30RB 170R-950R
30RB 170R 190R 210R 230R 270R 310R 340R 380R
Power circuit supply
Nominal voltage V-ph-Hz 400 - 3 - 50
Voltage range V 360 - 440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)or(2)
Circuit A&B kW 74,6 81,2 90,8 99,4 118,6 133,9 148,3 163,5
Power factor at maximum power
(1)or(2)
Displacement Power Factor (Cos Phi), standard unit 0,83 0,83 0,83 0,83 0,83 0,83 0,83 0,83
Maximum operating current draw (Un)
(1)or(2)
Standard unit A 129,0 141,2 157,8 172,0 205,2 231,6 256,5 282,9
Maximum current (Un-10%)
(1)or(2)
Standard unit A 137,7 150,6 168,6 183,6 219,6 247,5 274,5 302,4
Maximum start-up current (Un)
(2)+(3)
Standard unit A 305 354 370 348 418 444 469 496
Unit + option 25/25E A 262 302 318 305 366 392 417 444
30RB 410R 450R 480R 550R 610R 670R 720R 770R 800R 870R 950R
Power circuit supply
Nominal voltage V-ph-Hz 400 - 3 - 50
Voltage range V 360 - 440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)or(2)
Circuit A&B kW 178,4 193,7 208,1 237,8 256,4 282,7 306,1 328,5 340,2 374,4 405,6
Power factor at maximum power
(1)or(2)
Displacement Power Factor (Cos Phi), standard unit 0,85 0,85 0,85 0,85 0,84 0,84 0,84 0,84 0,84 0,84 0,84
Maximum operating current draw (Un)
(1)or(2)
Standard unit A 302,4 327,9 352,8 403,2 439,5 486,0 525,0 565,0 584,5 644,0 696,0
Maximum current (Un-10%)
(1)or(2)
Standard unit A 324 351 378 432 472 522 564 607 628 692 748
Maximum start-up current (Un)
(2)+(3)
Standard unit A 515 541 565 616 770 823 856 902 915 981 1027
Unit + option 25/25E A 463 489 513 564 687 740 773 819 832 898 944
(1) Values at the unit's permanent maximum operating condition (as shown on the unit's nameplate).
(2) Values at the unit's maximum operating condition (as shown on the unit's nameplate).
(3) Maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the largest compressor.
