0-8
HOW TO USE THIS MANUAL
EXPLANATION METHOD
1 Operating procedure
(1) Operating procedures are described using either pattern A or pattern B
(a) Pattern A: Each step of the operation is explained with its own illustration
(b) Pattern B: The entire operation is indicated by step numbers in one illustration, followed by
cautions, notes, and point operations
Example of pattern B
DISASSEMBLY · INSPECTION · REASSEMBLY
Tightening torque unit
T=Nm
Disassembly Procedure
1 Remove the cover [POINT 1]
2 Remove the bushing [POINT 2]
3 Remove the gear
Point Operations
[POINT 1]
Disassembly:
Make match marks before removing the pump cover
[POINT 2]
Inspection:
Measure the bushing inside diameter.
Limit 19.12 mm
• Some step numbers may be
omitted in some illustrations.
• When a part requiring
tightening torque instruction is
not indicated in the illustration,
the part name is described in
the illustration frame.
T = 46.1 to 48.1
(470 to 490)
[34.0 to 35.5]
1
2
3
4
7
6
5
8
5
9
1
Operation to be explained
Explanation of operation point with illustration
