CESAB B 200 - MECHANIC DISTRIBUTOR SYSTEM CONFIGURATION

4-6
MECHANIC DISTRIBUTOR SYSTEM CONFIGURATION
JT (20)
JT (21)
J40 (8)
J40 (15)
J34 (21)
J34 (22)
J34 (23)
J34 (33)
J34 (34)
J34 (35)
JP (20)
JP (21)
J133 (4)
J133 (5)
J132 (3)
J132 (4)
J137 (1)
J137 (2)
J137 (8)
J137 (9)
J131 (1)
J131 (2)
180 Ω
180 Ω
180 Ω
J148 (8)
J148 (13)
1 KΩ
LOGIC UNIT
TRACTION
LOGIC UNIT
LIFTING
SESAM KEYPAD
RESISTENCE
CAN-BUS
CAN-BUS SOCKET
PROGRAMMER
I/O CARD
WIRING HARNESS
DASHBOARD
CAN LOW
CAN HIGH
Color: GRAY/YELLOW
Color: BLUE/BLACK
CONTROL VALVE
MECHANICAL
