Mounting Options 8-9
5150 Service Aggregation Switch Hardware Installation and Start-up Manual
009-3222-001 Standard Revision H
Copyright
©
2012-2015 Ciena
®
Corporation July 2015
Figure 8-6
Front view of left bracket, showing mounting holes
7 Use the Cable Support Brackets to dress and secure the cables. Use local
practices to secure the cables. Ensure that the weight of the cable is
supported and does not drag on the plug. For detailed cabling information,
see the hardware installation manual for the unit.
You have successfully mounted the unit.
Inner cable bracket screw position
Frame
mounting
holes
Outer cable bracket screw position
To Next Page
