5-72
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 5 Install and Upgrade Internal Modules and FRUs
Install and Remove an SSD mSATA Storage Device
Remove the Flash Memory Card
Step 1 Read the “Safety Warnings” section on page 5-2, and disconnect the power supply before you replace
any module.
Step 2 Remove the chassis cover. For instructions on removing the chassis cover, see “Remove and Replace
Chassis Cover” section on page 5-4.
Step 3 Unscrew the flash memory card, see Figure 5-54.
Step 4 Install a new flash memory card if needed. See Install the Flash Memory Card, page 5-70.
Step 5 Replace the chassis cover. See “Remove and Replace Chassis Cover” section on page 5-4.
Install and Remove an SSD mSATA Storage Device
This section describes installing and replacing an SSD mSATA storage device in Cisco 4300 ISR routers.
• Prevent Electrostatic Discharge Damage, page 5-67
• Install the SSD mSATA Storage Device, page 5-73
• Remove the SSD mSATA Storage Device, page 5-74
Prevent Electrostatic Discharge Damage
The SSD mSATA storage devices are sensitive to electrostatic discharge (ESD) damage, which can occur
when electronic cards or components are handled improperly. ESD results in complete or intermittent
failures.
To prevent ESD damage, follow these guidelines:
• Always use an ESD wrist or ankle strap and ensure that it makes good skin contact.
• Connect the equipment end of the strap to an unfinished chassis surface.
• Place the SSD mSATA storage devices on an antistatic surface or in a static shielding bag. If the
device is to be returned to the factory, immediately place it in a static shielding bag.
• Avoid contact between the device and clothing. The wrist strap protects the device from ESD
voltages on only the body; ESD voltages on clothing can still cause damage.
• Do not remove the wrist strap until the installation is complete.
Caution For safety, periodically check the resistance value of the antistatic strap. The measurement should be
between 1 and 10 megohms (Mohms).
