3-28
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 3 Install and Connect Cisco 4000 Series ISRs
Connect WAN, LAN, and Voice Interfaces
metallically connected to interfaces that connect to the OSP or its wiring. These interfaces are designed
for use as intra-building interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE, Issue
4) and require isolation from the exposed OSP cabling. The addition of Primary Protectors is not
sufficient protection in order to connect these interfaces metallically to OSP wiring.
Warning Never install telephone jacks in wet locations unless the jack is specifically designed for wet
locations. Statement 1036
Warning Never touch uninsulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface. Statement 1037
Warning Class 1 laser product. Statement 1008
Ports and Cabling
Table 3-2 summarizes typical WAN, LAN, and voice connections for routers. The connections
summarized here are also described in detail in Cisco Modular Access Router Cable Specifications.
Table 3-2 WAN, LAN, and Voice Connections
Port or Connection Port Type, Color
1
Connection: Cable
Ethernet RJ-45, yellow Ethernet hub or Ethernet switch Category 5 or higher Ethernet
T1/E1 WAN
xCE1T1-PRI
RJ-48C/CA81A
RJ-48S, tan
T1 or E1 network
External T1 CSU or other
T1 equipment
RJ-48 T1/E1
RJ-48S to RJ-48S TE
RJ-48S to RJ-48S NT
RJ-48S to RJ-48S T1
RJ-48S to bare
RJ-48S to BNC
RJ-48S to twinaxial cable
RJ-48S to DB-15
RJ-48S to DB-15 null
T3/DS3/E3 WAN BNC connector T3 network, CSU/DSU, or other
T3/DS3 equipment
75-ohm coaxial cable
Cisco serial 60-pin D-sub, blue CSU/DSU and serial network or
equipment
Cisco serial transition cable that
matches the signaling protocol
(EIA/TIA-232, EIA/TIA-449, V.35,
X.21, or EIA-530)
and the serial port operating mode
(DTE or DCE).
Cisco Smart serial Cisco Smart compact
connector, blue
CSU/DSU and serial network or
equipment
T1/E1 digital voice RJ-48C/CA81A, tan Digital PBX, ISDN network,
CSU/DSU
RJ-48 T1/E1
Gigabit Ethernet SFP,
optical
LC, color according
to optical wavelength
1000BASE-SX, -LX, -LH, -ZX,
-CWDM
Optical fiber as specified on applicable
data sheet
Gigabit Ethernet SFP,
copper
RJ-45 1000BASE-T Category 5, 5e, 6 UTP
