Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of Cisco 4000 Series ISRs
Chassis Views
Platform Summary
Figure 1-6 shows the internal view of Cisco 4451-X ISR with parts and module locations.
Figure 1-10 Platform Summary of Cisco 4451-X ISR
Cisco 4431 ISR Chassis
Cisco 4431 ISR supports the Network Interface Modules (NIMs) and Integrated Services Card (ISC slots
for PVDM4s).
1
8
2
3
4
5
6
7
391821
1 Forwarding plane processor 2 Control plane processor
3 Control plane processor DIMMs 4 NIM 3 (single-wide) slot
5 Enhanced Service Module (SM-X) slots 6 NIM slot 1 and 2 (shown with slot divider
removed)
7 SFP GE ports 8 Forwarding plane processor DIMM
