1-22

Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router

OL-32185-02

Chapter 1 Overview of Cisco 4000 Series ISRs

Chassis Views

Figure 1-25 LEDs on Cisco 4321 ISR

For detailed information on LEDs, see the “LED Indicators” section on page 1-29.

Platform Summary

1 LEDs

391471
