Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Network Configuration
The Network Configuration area on a phone’s web page displays network configuration information and
information about other phone settings.
Table 8-2 describes this information.
You can view and set many of these items from the Network Configuration Menu and the Device
Configuration Menu on the Cisco
Unified IP Phone. For more information, see Chapter 5, “Configuring
Features, Templates, Services, and Users.”
To display the Network Configuration area, access the web page for the phone as described in the
“Accessing the Web Page for a Phone” section on page 8-2, and then click the Network Configuration
hyperlink.
Table 8-2 Network Configuration Area Items
Item Description
DHCP Server IP address of the Dynamic Host Configuration
Protocol (DHCP) server from which the phone obtains
its IP address.
BOOTP Server Indicates whether the phone obtains its configuration
from a Bootstrap Protocol (BootP) server.
MAC Address Media Access Control (MAC) address of the phone.
Host Name Host name that the DHCP server assigned to the
phone.
Domain Name Name of the Domain Name System (DNS) domain in
which the phone resides.
IP Address Internet Protocol (IP) address of the phone.
Subnet Mask Subnet mask used by the phone.
TFTP Server 1 Primary Trivial File Transfer Protocol (TFTP) server
used by the phone.
Default Router 1–5 Default router used by the phone (Default Router 1)
and optional backup routers (Default Router 2–5).
DNS Server 1–5 Primary Domain Name System (DNS) server (DNS
Server 1) and optional backup DNS servers (DNS
Server 2–5) used by the phone.
Operational VLAN ID Auxiliary Virtual Local Area Network (VLAN)
configured on a Cisco Catalyst switch in which the
phone is a member.
Admin. VLAN ID Auxiliary VLAN in which the phone is a member.
