Cisco C1101-4P Hardware Installation Guide

• Output voltage: +12VDC for system power and -53.5VDC for PoE power
Slots and Interfaces
About Slots, Subslots, and Port Numbering
The Cisco 1100 series designates its interfaces using a 3-tuple notation that lists the slot, sub slot and port in
the format slot/sub-slot/port. The slot number is reserved for the mother board, which is "0". Each interface
type is allocated a sub slot and the port number is a unique port on the interface.
Table 5: Slot, Bay, and Port Numbering
Interface TypeSubslot
Ethernet LAN0
Ethernet WAN1
LTE2
DSL3
Wi-Fi4
Specifications of Cisco 1000 Series Integrated Services Routers
For specifications on the Cisco 1000 Series Integrated Services Routers, refer to the Cisco 1100 Series ISR
Specifications document.
Periodic Inspection and Cleaning
We recommend that you periodically inspect and clean the external surface of the router. Removing is
recommended to minimize the negative impact of environmental dust or debris. The frequency of inspection
and cleaning is dependent upon the severity of the environmental conditions, but we recommend cleaning the
router once every six months. Cleaning involves vacuuming router air intake and exhaust vents.
Sites with ambient temperatures consistently above 25°C or 77°F and with potentially high levels of dust or
debris might require periodic preventative maintenance cleaning.
Note
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
21
Overview of Cisco 1000 Series Integrated Services Routers
Slots and Interfaces

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
