Cisco C1101-4P Hardware Installation Guide

FunctionColorLED
• Off: SIM0 is not installed
• Yellow: SIM0 is installed, but not active
• Green: SIM0 installed and active
• Green Blink: LTE data activity
SIM1 LED/ActivityGreen, YellowSIM1
• SIM1 LED status and WWAN activity
• Off: SIM1 is not installed
• Yellow: SIM1 is installed, but not active
• Green: SIM1 installed and active
• Green Blink: LTE data activity
GPS LEDGreen, YellowGPS
• Off: GPS is not configured
• Yellow: Software is defined
• Green: GPS is configured
• Green Blink: GPS is functional
Service Indication LED (Applicable for P-5GS6-GL)Green, Yellow, BlueService
• Yellow: 3G
• Green: 4G LTE
• Blue: 5G
RSSI LED (Applicable for P-LTE-XX, P-LTEA-XX,
P-LTEAP18-GL )
Green, YellowRSSI
• Green: 4G LTE
• Yellow: 3G
Attaching the Antennas
To attach the antenna in the Pluggable Interface Module, perform the below steps:
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
72
Install and Upgrade Internal Modules and Field Replaceable Units
Attaching the Antennas

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
