Cisco C1101-4P Hardware Installation Guide

Prepare for Router Installation
Before you install the Cisco 1000 Series Integrated Services Routers, you must prepare your site for the
installation. This chapter provides pre-installation information, such as recommendations and requirements
that should be considered before installing your router.
See the following sections to prepare for installation:
Ethernet Connections
The IEEE has established Ethernet as standard IEEE 802.3. The routers support the following Ethernet
implementations:
Supports the Ethernet maximum length of 328
feet (100 meters).
1000BASE-T—1000 Mb/s full-duplex transmission over a
Category 5 or better unshielded twisted-pair (UTP) cable.
Supports the Ethernet maximum length of 328
feet (100 meters).
100BASE-T—100 Mb/s full-duplex transmission over a
Category 5 or better unshielded twisted-pair (UTP) cable.
Supports the Ethernet maximum length of 328
feet (100 meters).
10BASE-T—10 Mb/s full-duplex transmission over a
Category 5 or better unshielded twisted-pair (UTP) cable.
See the Cisco Modular Access Router Cable Specifications document at Cisco.com for information about
Ethernet cables, connectors, and pinouts.
RequiredToolsandEquipmentforInstallationandMaintenance
You need the following tools and equipment to install and upgrade the router and its components:
• An ESD-preventive cord and a wrist strap
• A number 2 Phillips screwdriver
• Phillips screwdrivers: small, 3/16-in. (4 to 5 mm) and medium 1/4-in. (6 to 7 mm). You might need these
when you install or remove modules, and when you remove the cover (when you upgrade the memory
or other components)
• Screws that fit your rack
• A wire crimper
• A wire for connecting the chassis to an earth ground: AWG 14 (2 mm²) or larger wire
• An appropriate user-supplied UL or a CSA-certified ring terminal with an inner diameter of 1/4 in. (5 to
7 mm)
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
29
Prepare for Router Installation
Prepare for Router Installation

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
