Cisco C1101-4P Hardware Installation Guide

CHAPTER 3
Install and Connect the Router
This chapter describes how to install and connect Cisco 1000 Series Integrated Services Router to LAN and
WAN networks.
Read the installation instructions before using, installing or connecting the system to the power source.
Statement 1004
Warning
Installing the Cisco 1000 Series Integrated Services Router involve these tasks:
• Unpack the Router, on page 31
• Set up Router on Desktop, Rack, or Wall, on page 31
• Connect Power Cable, on page 49
• Connect the Router to a Console, on page 51
• Connect WAN and LAN Interfaces, on page 55
• Configure the Router at Startup, on page 56
Unpack the Router
Unpack the router only when you are ready to install it. If the installation site is not ready, to prevent accidental
damage, keep the chassis in its shipping container until you are ready to install.
The router, accessory kit, publications, and any optional equipment you order may be shipped in more than
one container. When you unpack the containers, check the packing list to ensure that you have received all
the listed items.
Set up Router on Desktop, Rack, or Wall
After unpacking, based on your requirements, you can set up a Cisco 1000 Series Integrated Services Router
on a desktop, a rack, or the wall.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
31

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
