Cisco IE 4010 User Manual

Synchronous Ethernet status11
PoE12
Display mode switch13
SD card slot cover14
Port LEDs
Each Ethernet port has a port LED. These port LEDs, display information about the individual ports. The port
mode determines the type of information shown by the port LEDs. The following table lists the mode LEDs
and their associated port modes and meanings
Table 3: Port Mode LEDs
DescriptionPort ModeMode LED
The port status. This is the default mode.Port statusAll Off
The port operating speed: 10, 100, 1000 mbps or
10 Gbps.
Port speedSPEED
The port duplex mode: full duplex or half duplex.Port duplex modeDUPLX
Parallel Redundancy Protocol (PRP) status.Redundancy statusREDUN
Not supported by software yet. Mode button skips
this LED.
Synchronous Ethernet statusSYNCE
The PoE+ port status.PoE+ port powerPoE
To select or change a mode, press the Mode button until the desired mode is highlighted. The Mode LED will
turn ON solid green when a mode is selected and turn OFF when timeout (5 seconds) or a different mode is
selected. When you change port modes, the meanings of the port LED colors also change. The following table
explains how to interpret the port LED colors in different port modes.
Cisco IE 4010 Switch Hardware Installation Guide
7
Product Overview
Port LEDs
