Port Management
Link Aggregation
SPS208G/SPS224G4/SPS2024 Service Provider Switches User Guide 44
3
Link Aggregation Detail
The Detail button displays the Link Aggregation Screen with the following fields:
STEP 1 Click Detail. The Link Aggregation Details Screen opens.
Figure 14 Link Aggregation Details Screen
The
Link Aggregation Details Screen contains the following fields:
LAG Configuration
• LAG — Defines the LAG ID number.
• Description — Defines the user-defined LAG name.
• LACP Mode — Enables or disables Link Aggregation Control Protocol
(LACP). The possible field values are:
- LACP — LACP is enabled on the LAG.
- Static — LACP is disabled on the LAG.
