DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
26 Unpacking and Setup
Then, use the screws provided with the equipment rack to
mount the switch on the rack.
Figure 2-2B. Installing the switch on an equipment rack
Power on
The DES-3326S switch can be used with AC power supply
100-240 VAC, 50 - 60 Hz. The power switch is located at the
rear of the unit adjacent to the AC power connector and the
system fan. The switch’s power supply will adjust to the local
power source automatically and may be turned on without
having any or all LAN segment cables connected.
After the power switch is turned on, the LED indicators should
respond as follows:
