DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
Identifying External Components 31
100BASE-FX Fiber Module (2Km/15Km)
Figure 3-5. 100BASE-FX two-port module
♦ Front-panel module.
♦ Two 100BASE-FX (with SC type connector) Fiber ports.
♦ Fully compliant with IEEE802.3u.
♦ Support Full-duplex operation only.
♦ IEEE 802.3x compliant Flow Control support for full-duplex.
1000BASE-T Module
Figure 3-6. 1000BASE-TX two-port module
