DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
Web-Based Switch Management 309
Router Ports
This displays which of the switch’s ports are currently
configured as router ports. A router port configured by a user
(using the console or Web-based management interfaces) is
displayed as a static router port, designated by S. A router port
that is dynamically configured by the switch is designated by D.
To view the Router Port table, click on the Router Ports
link:
Figure 6-99. Browse Router Port
S signifies a static router port, configured by the user.
D signifies a dynamically assigned router port, configured by
the switch.
IGMP Snooping Status
This allows the switch’s IGMP Snooping table to be viewed.
IGMP Snooping allows the switch to read the Multicast Group
To Next Page
